Thin Wall Wireline AW BW NW Delta 425 Drill Pipe

  • 1
  • 2
  • 3

Brand Name : ROSCHEN

Model Number : NTW

Certification : ISO

Place of Origin : CHINA

MOQ : Negotiable

Price : Negotiate

Supply Ability : 1000000 pcs

Packaging Details : Steel bundles

Product name : Drill Pipe

Usage : Underground mining

Advantage : high quality

Color : Black or as per your demands

Name : Delta 425 Drill Pipe

Wall thickness : 5-19mm

Item name : hard rock Mining Integral drill steel

Contact Now

Thin Wall Wireline AW BW NW Delta 425 Drill Pipe



Drill Pipe Introduction



Drill pipe, is hollow, thin-walled, steel or aluminium alloy piping that is used on drilling rigs. It is hollow to allow drilling fluid to be pumped down the hole through the bit and back up the annulus. It comes in a variety of sizes, strengths, and wall thicknesses, but is typically 27 to 32 feet in length (Range 2). Longer lengths, up to 45 feet, exist (Range 3).

Drill stems must be designed to transfer drilling torque for combined lengths that often exceed several miles down into the Earth's crust, and also must be able to resist pressure differentials between inside and outside (or vice versa), and have sufficient strength to suspend the total weight of deeper components. For deep wells this requires tempered steel tubes that are expensive, and owners spend considerable efforts to reuse them after finishing a well.



Drill Pipe Feature



1. Light weight (lighter than the old-fashioned drill pipe 45%)



2. Footage soon, dust small vertical holes left after drilling cuttings, into a hole clear.



3. Card beans quickly and easily connect and save banding material.





Drill Pipe Size available:



"Q" Series: BQ, NQ, HQ, PQ

"W" Series: RW, EW, AW, BW, NW, HW

"WJ" Series: AWJ, BWJ, NWJ, KWJ, HWJ

Metric Series: 33, 42, 50





Drill Pipe Parameters



Drill rod specification:

"Q" series: AQ, BQ, NQ, HQ, PQ, NQ3, HQ3, PQ3,
"TW" series: ATW, BTW, NTW, HTW,
"U" series (underground): AQU, BQU, NQU, HQU, ATWU, BTWU

Size O.D.(mm) I.D.(mm) Weight/3m (kg) Weight/1.5m (kg)
A 43.1 36.1 11 5.5
B 55.58 45.97 19.05 9.53
N 69.85 60.45 23.77 11.89
H 88.9 77.72 34.88 17.44
P 114.3 101.6 53.07 26.54
ATW 44.5 36.8 11.5 5.75
BTW 56.64 48.51 15.65 7.83
NTW 73.15 64.26 22.91 11.46
HTW 90.93 81.53 30.75 15.38

Size Length OD ID Weight
Standard Q thread or RQ thread
Drill rod, B 1.5 m 55.6mm 46mm 9.4kg
3m 18.6kg
Drill rod, N 1.5 m 71mm 60mm 13.5kg
3m 23.7kg
Drill rod, H 1.5 m 89mm 77.8mm 17.93kg
3m 35.84kg
Drill rod, P 1.5 m 114.3mm 101.6mm 26.79kg
3m 52.56kg



Drill Pipe Pictures



Thin Wall Wireline AW BW NW Delta 425 Drill Pipe

Thin Wall Wireline AW BW NW Delta 425 Drill Pipe
